Black Liquor Recovery Boilers

Metalspray® Cladding for Black Liquor Recovery Boilers (BLRBs)

IGS has decades of experience providing corrosion protection for carbon steel boiler tubes found in BLRBs. Common areas where our technology mitigates corrosion from high-temperature sulfidation attacks with our Metalspray® Cladding Systems:

  • WaterWall Tubes
  • Nose Arch Tubes
  • Superheaters Tubes

At IGS, we couple our technical expertise and our application experience together to ensure our customers receive long-term, reliable solutions, which increase their Recovery Boiler Reliability from a corrosion mitigation perspective. Our execution teams understand the dynamics of working in an outage environment and we recognize our customers’ need to meet their critical path maintenance schedules. IGS strives to deliver HVTS Metalspray® Cladding Systems on time, with the highest quality and safety standards in the industry.

Black Liquor Recovery Boilers: How to Prevent Tube Leaks

BLRB Boiler Safety Considerations

We have designed our Metalspray® Cladding Systems to protect the WaterWall Tube of Black Liquor Recovery Boilers from a general loss of wall thickness from the fireside of the furnace. With enhanced corrosion protection our customers introduce a corrosion protection factor onto their boiler tubes. A loss of tube thickness could result in the potential for a pin hole to develop in a boiler tube, which could create a boiler tube leak. The result being the mill would go into an Emergency Shutdown Procedure (ESP) which can have a significant impact on personnel safety if a smelt/water reaction were to take place.



IGS Experience Field

IGS has over 35 years of experience working in the Pulp & Paper Industry. Over the past 35 years, we have provided our Metalspray® Cladding Services to many of the leading Pulp & Paper Companies around the globe. Our team of experienced project managers, superintendents, foremen, safety managers, and HVTS technicians ensures that IGS is always ready to deliver high quality in situ Metalspray® Cladding applications, anytime and anywhere. Because we are a global company, we do not rely on increasing our pool of technicians with part-time help in the spring and fall busy periods and then reducing our pool of technicians in the winter and summer. It is always BLRB outage season somewhere around the globe, so we maintain a strong experienced workforce year around.

Image: Micrograph of IGS Corrosion Resistant Coating for BLRB

IGS Cladding Shop

IGS also has a state-of-the-art shop facility where we can process new replacement waterwall boiler tube panels. In this shop, we apply our Metalspray® Cladding with automation to the new waterwall panels. After coating, the panels are being delivered to the site and installed for service. This option allows our customers to design long-term corrosion protection solutions. HVTS Cladding enhances the corrosion protection factor of the carbon steel tubes and extends their run time considerably.

IGS Cladding Technology

Our core technology is the IGS High-Velocity Thermal Spray (HVTS) metal alloy cladding system. We utilize HVTS  to provide a field-installed CRA to mitigate corrosion in BLRB process environments. Our HVTS cladding systems typically utilize modified super alloys with proven performance in high-temp conditions. We provide a protective layer on the fireside of black liquor recovery boiler tubes, digesters, and flash tanks.

Free Consultation with IGS Subject Matter Expert

IGS is here to provide information, answer questions and create an effective solution for your needs.
